Wi-Fi SMART PIR motion sensor for surface mounting 110°, 6m, IP20

Aрт. № WFSDVM
Wi-Fi SMART PIR motion sensor for surface mounting 110°, 6m, IP20
Wi-Fi SMART PIR motion sensor for surface mounting 110°, 6m, IP20 Wi-Fi SMART PIR motion sensor for surface mounting 110°, 6m, IP20 Wi-Fi SMART PIR motion sensor for surface mounting 110°, 6m, IP20

Wi-Fi SMART PIR motion sensor for surface mounting 110°, 6m, IP20

Art № WFSDVM
description:

The product is a passive infra-red (PIR) sensor, which detects the infra-red rays (heat) emitted from the objects in its operating range. The sensor would work depending on the changes in the heat background of the area. Therefore, it is not recommended to install the sensor in areas with greater temperature amplitudes – near air conditioners or other heating devices.
WFSDVM works with TUYA – a smartphone app. It is used as a motion sensor and sends notifications to the smartphone. It could also be used for different lighting settings (like switching on/off WI-FI SMART lighting, sockets and switches that supply different type of electrical consumers). With the WI-FI SMART products one can develop an intelligent system operated via smartphone (tablet) or voice assistant.

specifications:
RF frequency 2.4 GHz
Protection rating IP20
Working temperature range 0 ⁰C ÷ +40 ⁰C
Dimensions 64/64/80mm
Detection distance 6m
Installation height 2.2 - 4m
Ambient light <3-2000lx
Detection range 110°
Battery 3 x AAA
Warranty 2 years
description:

The product is a passive infra-red (PIR) sensor, which detects the infra-red rays (heat) emitted from the objects in its operating range. The sensor would work depending on the changes in the heat background of the area. Therefore, it is not recommended to install the sensor in areas with greater temperature amplitudes – near air conditioners or other heating devices.
WFSDVM works with TUYA – a smartphone app. It is used as a motion sensor and sends notifications to the smartphone. It could also be used for different lighting settings (like switching on/off WI-FI SMART lighting, sockets and switches that supply different type of electrical consumers). With the WI-FI SMART products one can develop an intelligent system operated via smartphone (tablet) or voice assistant.
