LED Ceiling lamp with microwave dimming sensor, square 12W, 4000K, 220-240V AC

Aрт. № SPLM1240D
LED Ceiling lamp with microwave dimming sensor, square 12W, 4000K, 220-240V AC
LED Ceiling lamp with microwave dimming sensor, square 12W, 4000K, 220-240V AC LED Ceiling lamp with microwave dimming sensor, square 12W, 4000K, 220-240V AC

LED Ceiling lamp with microwave dimming sensor, square 12W, 4000K, 220-240V AC

Art № SPLM1240D
description:

Microwave sensors have higher sensitivity and greater detection range compared to PIR sensors. So, Ultralux® LED ceiling lamps with microwave sensor are suitable for lighting up houses and places where automation of the lighting is necessary. The signal of the microwave sensor can pass freely through wood, glass and thinner walls. That is why LED ceiling lamps with microwave sensors are not suitable for lighting up outdoor areas.

Features of the ceiling lamp:

  • flicker-free
  • color temperature consistency
  • compact slim design
  • PVC diffuser
  • Powder coated steel housing
  • aluminium PCB
  • high quality LEDs
  • fast and easy installation
  • economical investment cost
  • energy saving up to 80%

Main features of the sensor:

  • When there is sufficient ambient light, the sensor will not turn on the light.
  • When the light is insufficient, the sensor will turn on the light if movement is detected in the area.
  • If there is no movement in the detection area and the time delay is over at maximum power, the sensor will dim the light.
  • When the stand-by period is over at dimmed level, the sensor will turn off the light, if there is no movement in the detection area.



specifications:
Power 12W
Voltage AC 220-240V
Frequency 50-60Hz
Class II
Dimmable yes
Sensor working frequency 5.8GHz
Output signal power <0,2mW
Protection rating IP20
Working temperature range -10 °C ÷ +40 °C
On/Off cycles 15000
Dimming level 10%, 20% (регулируемо)%
Dimensions 250/250/58mm
Lumen Maintenance LM80 25000h
Colour white
Detection distance 5-15 (стена) / 2-8 (таван)m
Installation height 1.5-3.5 (стена) / 2-4 (таван)m
Ambient light 5/15/50//2000lx
Detection range 180°/360°
Self consumption 0.9W
Starting time <0.2sec
Warranty 2 years
Shape square
Detection moving speed 0.6-1.5m/s
Working humidity <93%RH
Operating time at full power 10sec/90sec/3min/10minmin
Rated luminous flux 850lm
Correlated Color Temperature (CCT) 4000K
Color Rendering Index (CRI) >80
Beam angle 120⁰
LED type SMD5730
description:

Microwave sensors have higher sensitivity and greater detection range compared to PIR sensors. So, Ultralux® LED ceiling lamps with microwave sensor are suitable for lighting up houses and places where automation of the lighting is necessary. The signal of the microwave sensor can pass freely through wood, glass and thinner walls. That is why LED ceiling lamps with microwave sensors are not suitable for lighting up outdoor areas.

Features of the ceiling lamp:

  • flicker-free
  • color temperature consistency
  • compact slim design
  • PVC diffuser
  • Powder coated steel housing
  • aluminium PCB
  • high quality LEDs
  • fast and easy installation
  • economical investment cost
  • energy saving up to 80%

Main features of the sensor:

  • When there is sufficient ambient light, the sensor will not turn on the light.
  • When the light is insufficient, the sensor will turn on the light if movement is detected in the area.
  • If there is no movement in the detection area and the time delay is over at maximum power, the sensor will dim the light.
  • When the stand-by period is over at dimmed level, the sensor will turn off the light, if there is no movement in the detection area.
