Professional LED strip 12W/m, Dim-to-warm, 1800K-3000K, 24V DC, 280LEDs/m, SMD2216, 5m, IP20

Aрт. № PN22280DA
new
Professional LED strip 12W/m, Dim-to-warm, 1800K-3000K, 24V DC, 280LEDs/m, SMD2216, 5m, IP20
Professional LED strip 12W/m, Dim-to-warm, 1800K-3000K, 24V DC, 280LEDs/m, SMD2216, 5m, IP20 Professional LED strip 12W/m, Dim-to-warm, 1800K-3000K, 24V DC, 280LEDs/m, SMD2216, 5m, IP20 Professional LED strip 12W/m, Dim-to-warm, 1800K-3000K, 24V DC, 280LEDs/m, SMD2216, 5m, IP20 Professional LED strip 12W/m, Dim-to-warm, 1800K-3000K, 24V DC, 280LEDs/m, SMD2216, 5m, IP20

Professional LED strip 12W/m, Dim-to-warm, 1800K-3000K, 24V DC, 280LEDs/m, SMD2216, 5m, IP20

Art № PN22280DA
Energy class F
description:

Professional LED Strip DIM-TO-WARM with the following advantages:

  • The colour temperature of the emitted light varies between 3000K (warm light) and 1800K (amber) depending on the level of dimming. At 100% brightness the colour temperature is 3000K. By lowering the brightness, the colour temperature steadily decreases. The minimal brightness for the colour temperature is 1800K. This effect can be achieved only by using Ultralux dimmers (with pulse-width modulation);
  • The colour-rendering index is Ra≥90, meaning that the colours of objects under the light source have a maximum possible similarity to the way they would look under natural sunglight.
  • Minimal heat and electrical losses;
  • Double-layered PCB with a total thickness of 4 oz;
  • Flexible PCBs (99.99% Cu);
  • Standard deviation colour matching (SDCM)<3;
  • High efficiency;
  • High quality component;
  • Double adhesive tape 3М;
  • The width of the strip is 10 mm. It is suitable to use with every aluminum profiles from the Ultralux range (the use of aluminum profile is a mandatory condition);
  • The ingress protection rate is IP20. The product is intended for use in normal levels of dust and damp.
specifications:
Power per meter 12W/m
Voltage DC 24V
Dimmable PWM and voltage dimming
Protection rating IP20
Working temperature range -10 °C ÷ +40 °C
Lumen Maintenance LM80 >50000h
Starting time <0.2sec
Strip width 10mm
Strip length 5m
Warranty 3 years
LEDs per meter 280LEDS/m
Correlated Color Temperature (CCT) 1800K-3000K
Color Rendering Index (CRI) ≥90
Beam angle 120⁰
LED type SMD2216
luminous flux per meter 1150lm/m
description:

Professional LED Strip DIM-TO-WARM with the following advantages:

  • The colour temperature of the emitted light varies between 3000K (warm light) and 1800K (amber) depending on the level of dimming. At 100% brightness the colour temperature is 3000K. By lowering the brightness, the colour temperature steadily decreases. The minimal brightness for the colour temperature is 1800K. This effect can be achieved only by using Ultralux dimmers (with pulse-width modulation);
  • The colour-rendering index is Ra≥90, meaning that the colours of objects under the light source have a maximum possible similarity to the way they would look under natural sunglight.
  • Minimal heat and electrical losses;
  • Double-layered PCB with a total thickness of 4 oz;
  • Flexible PCBs (99.99% Cu);
  • Standard deviation colour matching (SDCM)<3;
  • High efficiency;
  • High quality component;
  • Double adhesive tape 3М;
  • The width of the strip is 10 mm. It is suitable to use with every aluminum profiles from the Ultralux range (the use of aluminum profile is a mandatory condition);
  • The ingress protection rate is IP20. The product is intended for use in normal levels of dust and damp.
