Digital RGB LED flexible strip, 25.8W/m (0,43W/pixel), IC WS2815B, 12V DC, 60 pixels/m (60 LED/m), IP20, 5m

Aрт. № PN5060DIG
Digital RGB LED flexible strip, 25.8W/m (0,43W/pixel), IC WS2815B, 12V DC, 60 pixels/m (60 LED/m), IP20, 5m
Digital RGB LED flexible strip, 25.8W/m (0,43W/pixel), IC WS2815B, 12V DC, 60 pixels/m (60 LED/m), IP20, 5m Digital RGB LED flexible strip, 25.8W/m (0,43W/pixel), IC WS2815B, 12V DC, 60 pixels/m (60 LED/m), IP20, 5m Digital RGB LED flexible strip, 25.8W/m (0,43W/pixel), IC WS2815B, 12V DC, 60 pixels/m (60 LED/m), IP20, 5m

Digital RGB LED flexible strip, 25.8W/m (0,43W/pixel), IC WS2815B, 12V DC, 60 pixels/m (60 LED/m), IP20, 5m

Art № PN5060DIG
description:

The new line of Ultralux RGB LED digital strips uses a WS2815B IC chip, 12 V DC supply voltage, and have 60 diodes per meter and 10 mm width.

Advantages:

  • IC chip WS2815B – each diode is a pixel. If a problem occurs only the defected pixel would go off, allowing quick detection and maintenance.
  • The strip could be operated with all the Ultralux controllers for digital lighting.
  • The cutting of the strip could be carried out at each pixel, through the copper plates.
  • Supply voltage is now 12 V DC and therefore:
    1. The strip emits less heat.
    2. The voltage drop is significantly reduced.
    3. The range of Ultralux 12 V DC power supplies offer a wider choice.
  • Double-layer PCB with total thickness of 3 oz, made from 99% copper.
  • Double-adhesive strip 3М.
  • The strip is compatible with all the Ultralux aluminum profiles.
  • The strip’s ingress protection rate is IP20 (non-waterproof), but if needed, it could be easily placed in a silicone tube (prod. code ST1010) that will ensure a higher protection rate IP66.
  • Double-ended power supply per each 5 meters is recommended.

The product is intended for professional use in effect and decorative lighting projects (casinos, clubs, hotels, restaurants, and façade lighting).

Minimum order quantity: 5 meters (1 roll).

specifications:
Power per meter 25.8W/m
Voltage DC 12V
Dimmable yes
Protection rating IP20
Working temperature range -10 °C ÷ +40 °C
Lumen Maintenance LM80 50000h
Starting time <0.2sec
Strip width 10mm
Strip length 5m
Warranty 3 years
LEDs per meter 60LEDS/m
Beam angle 120⁰
LED type SMD5050
Type of light RGB
Number of pixels 60/m
description:

The new line of Ultralux RGB LED digital strips uses a WS2815B IC chip, 12 V DC supply voltage, and have 60 diodes per meter and 10 mm width.

Advantages:

  • IC chip WS2815B – each diode is a pixel. If a problem occurs only the defected pixel would go off, allowing quick detection and maintenance.
  • The strip could be operated with all the Ultralux controllers for digital lighting.
  • The cutting of the strip could be carried out at each pixel, through the copper plates.
  • Supply voltage is now 12 V DC and therefore:
    1. The strip emits less heat.
    2. The voltage drop is significantly reduced.
    3. The range of Ultralux 12 V DC power supplies offer a wider choice.
  • Double-layer PCB with total thickness of 3 oz, made from 99% copper.
  • Double-adhesive strip 3М.
  • The strip is compatible with all the Ultralux aluminum profiles.
  • The strip’s ingress protection rate is IP20 (non-waterproof), but if needed, it could be easily placed in a silicone tube (prod. code ST1010) that will ensure a higher protection rate IP66.
  • Double-ended power supply per each 5 meters is recommended.

The product is intended for professional use in effect and decorative lighting projects (casinos, clubs, hotels, restaurants, and façade lighting).

Minimum order quantity: 5 meters (1 roll).
