Two-way proximity sensor 500W/200W, 220-240V AC

Aрт. № SB2
new
Two-way proximity sensor 500W/200W, 220-240V AC
Two-way proximity sensor 500W/200W, 220-240V AC

Two-way proximity sensor 500W/200W, 220-240V AC

Art № SB2
description:

The product has two detectors that emit infrared light, invisible for the human eye. By waving a hand (not farther that 5 cm from the sensor) this light is reflected and sent back to the detector and they, in turn, switch on/off the lighting. The two detectors could serve as deviator switches, meaning that the lights could be turned on/off from either one of the detectors. The length of the wires between the detectors and the actual sensor is 1.5 m per each. The sensor is widely used in concealed and cabinet lighting and has the following advantages:

  • Easy control: The lighting could be switched on/off from two different spots by simply waving a hand.
  • Security and comfort: Use even when your hands are wet or dirty – you only need to wave a hand in front of the detector to switch the lights on/off.
  • Universal compatibility: Could be used for incandescent lamps (R), as well as for LED lamps (C).
  • Intuitive design: Suitable for almost every room at one’s home (kitchen, bedroom, corridor).
  • Modern technology: The sensor’s operation mode makes it sensitive and reliable, immediately reacting to movement.
  • Quick mounting: The installation is quick and easy, without needing any specialized and expensive tools to be carried out with.
  • Compact dimensions: 102/40/17 mm.
specifications:
Voltage AC 220-240V
Frequency 50-60Hz
Class II
Maximum load (active/reactive) 500/200W
Protection rating IP20
Working temperature range -20 ⁰C ÷ +40 ⁰C
Dimensions 102/40/17mm
Mounting hole 14mm
Detection distance 0.05m
Self consumption 0.5W
Warranty 2 years
Working humidity <93%RH
description:

The product has two detectors that emit infrared light, invisible for the human eye. By waving a hand (not farther that 5 cm from the sensor) this light is reflected and sent back to the detector and they, in turn, switch on/off the lighting. The two detectors could serve as deviator switches, meaning that the lights could be turned on/off from either one of the detectors. The length of the wires between the detectors and the actual sensor is 1.5 m per each. The sensor is widely used in concealed and cabinet lighting and has the following advantages:

  • Easy control: The lighting could be switched on/off from two different spots by simply waving a hand.
  • Security and comfort: Use even when your hands are wet or dirty – you only need to wave a hand in front of the detector to switch the lights on/off.
  • Universal compatibility: Could be used for incandescent lamps (R), as well as for LED lamps (C).
  • Intuitive design: Suitable for almost every room at one’s home (kitchen, bedroom, corridor).
  • Modern technology: The sensor’s operation mode makes it sensitive and reliable, immediately reacting to movement.
  • Quick mounting: The installation is quick and easy, without needing any specialized and expensive tools to be carried out with.
  • Compact dimensions: 102/40/17 mm.
