Power supply 0-12V DC, 200W, IP20

Aрт. № ZNWJ12200
Power supply 0-12V DC, 200W, IP20

Power supply 0-12V DC, 200W, IP20

Art № ZNWJ12200
description:

UltraLux LED strip power supplies convert standard AC voltage (230V AC) into a constantly stabilized output voltage of 5V, 12V, 24V, 48V DC (depending on the model). They are manufactured using the latest technologies with quality electronic components. They have compact size, high efficiency (over 90%), low heat loss (no cooling fan), built-in protection against overload, overheat and short-circuit, do not emit electromagnetic interference.

The model has the following features:

  • adjustable output voltage in a in a wide range 0-12 V DC +15%;
  • adjustable input supply voltage: 90-130V AC / 180-260 V AC.
specifications:
Input voltage AC 90-130 / 180-260V
Frequency 50-60Hz
Maximum power 200W
Output voltage 0-12V
Class I
Maximum current 16.7A
Protection rating IP20
Working temperature range -10 °C ÷ +40 °C
Dimensions 198/98/45mm
Warranty 2 years
description:

UltraLux LED strip power supplies convert standard AC voltage (230V AC) into a constantly stabilized output voltage of 5V, 12V, 24V, 48V DC (depending on the model). They are manufactured using the latest technologies with quality electronic components. They have compact size, high efficiency (over 90%), low heat loss (no cooling fan), built-in protection against overload, overheat and short-circuit, do not emit electromagnetic interference.

The model has the following features:

  • adjustable output voltage in a in a wide range 0-12 V DC +15%;
  • adjustable input supply voltage: 90-130V AC / 180-260 V AC.
