Dimmable TRIAC driver for LED lighting 40W/850 mA

Aрт. № DDLP22040
Dimmable TRIAC driver for LED lighting 40W/850 mA

Dimmable TRIAC driver for LED lighting 40W/850 mA

Art № DDLP22040
description:

The TRIAC driver is designed to control (on, off and dim) LED luminaires with constant current power supply .

  • Works with Leading Edge / Trailing Edge dimmers.
  • The driver is flicker-free and has a power factor PF> 0.9.
  • Suitable for LED panels with 850 mA DC input current.
  • Compatible with TRIAC dimming switches for RC load.

Make sure the driver is not covered and have space around it for good heat desipation!

specifications:
Max output power DC 40W
Input voltage AC 220-240V
Frequency 50-60Hz
Power factor >0.9
Output current 850mA
Dimmable yes
Max output voltage DC 27-44V
Protection rating IP20
Working temperature range -10 °C ÷ +40 °C
Dimensions 210/40/30mm
Dimming range 0-100%
Control type TRIAC control
Warranty 2 years
Flicker Flickerless
description:

The TRIAC driver is designed to control (on, off and dim) LED luminaires with constant current power supply .

  • Works with Leading Edge / Trailing Edge dimmers.
  • The driver is flicker-free and has a power factor PF> 0.9.
  • Suitable for LED panels with 850 mA DC input current.
  • Compatible with TRIAC dimming switches for RC load.

Make sure the driver is not covered and have space around it for good heat desipation!
