Microwave sensors have higher sensitivity and greater detection range compared to PIR sensors. The signal of the microwave sensor can pass freely through wood, glass and thinner walls.
Ultralux® sensor MSOM is designed for wall mounting. It can work with incandescent lamps and LED lighting. Its ingress protection rate IP44 makes it suitable for areas with moderate levels of dust and moisture.
Function:
| Voltage AC | 220-240V |
| Frequency | 50-60Hz |
| Maximum load (active/reactive) | 1200/300W |
| Sensor working frequency | 5.8GHz |
| Output signal power | <0,2mW |
| Protection rating | IP44 |
| Working temperature range | -20 ⁰C ÷ +40 ⁰C |
| Time delay | 10 sec. - 12min |
| Detection distance | 1-8m |
| Installation height | 1,5-3,5m |
| Ambient light | <3-2000lx |
| Detection range | 360°/180° |
| Self consumption | 0.9W |
| Warranty | 2 years |
| Detection moving speed | 0.6-1.5m/s |
| Working humidity | <93%RH |
